- 16CH 4K DVR: The 4K DVR supports up to 8MP analog wired cameras. Record crisp & clean videos at true 4K resolution (3840 X 2160 pixels)
- AI Motion Detection DVR: Enabling the human & vehicle detection feature to get real time APP push and alerts when motion is detected
- 5-in-1 Hybrid DVR: The digital video recorder supports up to 16pcs 8MP TVI/AHD/CVI/CVBS and extra 4 IP cameras. Worry no more for camera signal
- H.265 DVR: Advanced H.265 video compression tech saves up to 80% of storage space compared to H.264 one
- Remote Access DVR: Download ANNKE Vision App to control the DVR via phone, tablet, computer and browser to realize remote access
DVR Specification:
· 4K(8MP) high definition live viewing, recording & playback
· 16CH Analog and 16 CH IP camera input simultaneously
· Deep learning-based motion detection 2.0 for all analog channels
· Deep learning-based perimeter protection
· Up to 32-ch IP camera inputs (up to 8 MP)
· H.265 Pro /H.265 Pro/H.265 video compression
· Support TVI/AHD/CVI/CVBS/IPC input. 5 in 1
· Supports iPhone、iPad、Android mobile remote monitoring
· Up to 10 TB capacity per HDD
· Audio via coaxial cable
Video Compression: H.264 /H.264/H.265/H.265
Video Input: 16CH Analog HD/Analog 16CH IP(Enhanced IP mode on)
Video Output: CVBS; VGA up to 1080p; HDMI up to 4K
Audio Input/Output: 1/1 RCA
Supported Analog Camera Types "Support HD TVI Input: 8MP, 5MP, 4MP, 3MP, 1080p@30 fps, 1080p@25 fps;
Support AHD Input: 5MP, 4MP, 1080p@25 fps, 1080p@30 fps;
Support CVI Input: 5MP, 4MP, 1080p@25 fps, 1080p@30 fps;
Support CVBS Input"
Analog HD Playback Resolution: "4K@8 fps/5MP@12 fps/4MP@15 fps/3MP@18 fps 1080p"
IP Camera Input: 16CH(up to 32-ch)
IPC Recording Resolution: Up to 8MP
IPC Playback Resolution: Up to 8MP
Max Playback Channel: 16CH
HDD: 2 SATA Interface
HDD Capacity: Up to 10 TB Capacity
